Vent-MAXX Double Layer PTFE for Sterilization in Air & Vent Gas Applications

Strainrite's Vent-MAXX gas sterilizing filters set a new standard for PTFE membrane elements. These filters utilize a technologically advanced membrane in our unique pleat construction to deliver unrivalled efficiency, superior strength, and high flow rates.

Download Spec Sheet (PDF)

Vent-MAXX Double Layer PTFE for Sterilization in Air & Vent Gas Applications

Technical Specifications

Filtration Performance

Specification	Detail
Maximum Differential Pressure	Forward: 75 psid (5.1 bar) @ 75°F (24°C), 40 psid (2.8 bar) @ 180°F (82°C) Reverse: 50 psid (3.4 bar) @ 75°F (24°C)
Maximum Operating Temperature	180°F (82°C) continuous duty
Integrity Test Values	All cartridges are integrity tested prior to shipment using pressure decay test method. Values below are for cartridges wetted with 100% IPA. 10": test pressure 14 psi, diffusional flow 25 mL/min 20": test pressure 14 psi, diffusional flow 50 mL/min 30": test pressure 14 psi, diffusional flow 75 mL/min

Materials & Compliance

Specification	Detail
Filter Media	Double layer PTFE
End Caps / Cage / Core	Polypropylene
Pleat Support Material	Polypropylene
End Cap Insert	316 Stainless Steel
Seals	Fluorocarbon, Silicone
Construction Method	Thermal bond
Toxicity	Cartridge materials meet USP Class VI and CFR 21 for food and beverage contact

Advanced Features

Specification	Detail
Sterilization	Vent-MAXX cartridges have been validated for bacterial removal in air at an aerosol bacterial challenge level of Brevundimonas diminuta at 10⁷ per cm² per ASTM (F 838-05). Liquid challenge validated as sterilizing grade filter at a challenge level of Brevundimonas diminuta at 10⁷ per cm² per ASTM (F 838-05). Water Intrusion Test (WIT) value of > 60 psi with a WIT not to exceed 75 psi.
Packaging Economy	Bulk packaging in case quantities: 5 inch - 48 per carton \| 10 inch - 24 per carton \| 20 inch - 12 per carton \| 30 inch - 12 per carton

Physical Specifications

Specification	Detail
Outside Diameter	2.7" (6.87 cm)
Approximate Surface Area	7.5 square feet per 10" equivalent
Lengths	5 inch (12.7 cm) \| 10 inch (25.4 cm) \| 20 inch (50.8 cm) \| 30 inch (76.2 cm)

Product Overview

Vent-MAXX double layer PTFE membrane filters are designed to remove microorganisms, particulate, and moisture in your most demanding air and gas applications. These liquid validated sterilizing grade filters are designed to meet the highest levels of security required in the pharmaceutical, food and beverage, and biopharmaceutical industries.

Vent-MAXX filters conform to USP Class VI – 121°C and 21 CFR Part 177. Strainrite delivers clear solutions to your air and gas filtration applications.
