Pur-MAXX N / Mem-Pleat N
Pleated nylon membrane cartridges are highly retentive, naturally hydrophilic nylon membrane filters that are specially designed for critical filtration requirements of aqueous fluids.
Technical Specifications
Filtration Performance
| Specification | Detail |
|---|---|
| Absolute Rated Retention | 0.1, 0.2, 0.45, 0.65, 0.8, 1.2 |
| Maximum Differential Pressure |
Forward: 75 psid (5.1 bar) @ 75°F (24°C), 40 psid (2.8 bar) @ 180°F (82°C) Reverse: 50 psid (3.4 bar) @ 75°F (24°C) |
| Maximum Operating Temperature | 180°F (82°C) continuous duty polypropylene; 275°F (135°C) continuous duty polyester |
Materials & Compliance
| Specification | Detail |
|---|---|
| Filter Media | Nylon 6,6 cast on polyester |
| End Caps | Polypropylene, polyester |
| Pleat Support Material | Polypropylene, polyester |
| Cage/Core | Polypropylene, polyester |
| Seals | Buna N, Fluorocarbon, EPDM, Silicone, FEP Encapsulated Fluorocarbon, FEP Encapsulated Silicone, PTFE Foam, PTFE Hard |
| Construction Method | Thermal bond |
| Toxicity | Cartridge materials meet CFR 21 for food and beverage contact |
Advanced Features
| Specification | Detail |
|---|---|
| Sterilization | Cartridge can be sterilized via steam or autoclave. Cartridge may be sanitized in place with common sanitizing agents; contact factory for chemical compatibility. |
| Packaging Economy | Bulk packaging in case quantities to reduce material disposal: 5 inch - 48 per carton, 10 inch - 24 per carton, 20 inch - 12 per carton, 30 inch - 12 per carton, 40 inch - 9 per carton |
Physical Specifications
| Specification | Detail |
|---|---|
| Outside Diameter | MPN: 2.55" (6.48 cm) | PRMXN: 2.7" (6.87 cm) |
| Approximate Surface Area | 6.8 square feet per 10" equivalent |
| Lengths | 5 inch (12.7 cm), 10 inch (25.4 cm), 20 inch (50.8 cm), 30 inch (76.2 cm), 40 inch (102 cm) |
Product Overview
The Nylon 6,6 membrane, in an all-polypropylene construction*, provides excellent wet-out characteristics and superior flow performance per surface area as compared to other membrane cartridges. No additives, resins, surfactants or binders are used in the manufacturing process, which dramatically reduces rinse up time, extractables and downtime.
These cartridges are perfectly suited for critical applications where superior flow, and particle removal efficiency between 0.1 and 1.2 micron is required.
The Pur-MAXX N now offers a Special Pleat option, which provides expected surface area improvements of as much as 25%. This optimized pleat geometry option was developed for the filtration of process fluids that require a high degree of particle retention and/or constant bacterial barrier for effective sterilization.
*Filter medium is cast on a polyester support.
Features & Benefits
100% hydrophilic materials of construction that are FDA listed as suitable for contact with food and beverage
Absolute-rated media provides reliable, consistent and repeatable filtrate quality
No adhesives, binders, resin or surfactants are used during manufacturing, resulting in superior downstream cleanliness
Lower filter extractables than other hydrophilic membranes
High surface area, yielding lower pressure drops and longer filter life
Non fiber-shedding polyester and polypropylene support materials eliminate fiber migration
Pharmaceutical grade elements are 100% integrity tested
IPA pre-wetting not required
Integrity testable
Special Pleat Option: Optimized pleat geometry
Special Pleat Option: Expected surface area improvements of as much as 25%
Recommended Vessels
Vessels and housings recommended for use with this product.
Markets & Applications
Fine Chemicals
Biological Fluids
API Chemicals
Reagent Grade Chemicals
