Madd MAXX XL
Strainrite's MADD-MAXX XL elements feature the proven benefits of small fiber diameter and a high void area, creating the perfect depth filter. These elements offer 5 to 10 times more surface area, depending upon chosen configuration and materials of construction. Coupled with a single O-ring positive seal, resulting in the most reliable, and versatile filters available.
Technical Specifications
Filtration Performance
| Specification | Detail |
|---|---|
| Micron Rating | 1T, 1, 5, 10, 25, 50, 75, 100, 200 |
| Maximum Operating Temperature | 180°F (82°C) continuous duty |
| Maximum Differential Pressure | 25 PSID @ 70°F (21°C) |
Materials & Compliance
| Specification | Detail |
|---|---|
| Filter Media | Polypropylene felt |
| Hardware | Polypropylene |
| Support Material | Polypropylene |
| Cage | Polypropylene rigid resin bonded felt |
| O-Rings | Buna N, Fluorocarbon, EPDM, Silicone |
| Construction Method | Thermal bond |
Physical Specifications
| Specification | Detail |
|---|---|
| Nominal Top Outside Diameter | 6.75" – 7.45" |
| Nominal Surface Area |
P1 - 8 square feet P2 - 18 square feet P3 - 22 square feet P4 - 30 square feet |
| Nominal Lengths |
P1 - 12" (30.5 cm) P2 - 26" (66.3 cm) P3 - 30" (76.5 cm) P4 - 40" (102 cm) |
Features & Benefits
Increased surface area offers higher flow capacity in existing applications
Lower initial differential pressure, reducing filtration costs, due to longer element life
Single O-ring sealing flange for increased efficiency
Thermally bonded end caps eliminating bypass
Internal polymeric pleat separator to assure full utilization of the entire pleat surface area
Recommended Vessels
Vessels and housings recommended for use with this product.
Markets & Applications
Reagent Grade Chemicals
General Water Filtration
Wastewater
Amine Fluids
Glycol Fluids
Food & Beverage
DI/RO Prefiltration
Edible Oils
