Pur-MAXX T / Mem-Pleat T

Pleated PTFE membrane cartridges were developed for critical filtration applications where PTFE and polypropylene materials are compatible.

Download Spec Sheet (PDF)

Technical Specifications

Filtration Performance

Specification	Detail
Absolute Rated Retention	0.1, 0.2, 1, 3
Maximum Differential Pressure	Forward: 75 psid (5.1 bar) @ 75°F (24°C), 40 psid (2.8 bar) @ 180°F (82°C) Reverse: 50 psid (3.4 bar) @ 75°F (24°C)
Maximum Operating Temperature	180°F (82°C) continuous duty

Materials & Compliance

Specification	Detail
Filter Media	PTFE
End Caps	Polypropylene
Pleat Support Material	Polypropylene
Cage/Core	Polypropylene
Seals	Buna N, Fluorocarbon, EPDM, Silicone, FEP Encapsulated Fluorocarbon, FEP Encapsulated Silicone, PTFE Foam, PTFE Hard
Construction Method	Thermal bond
Toxicity	Cartridge materials meet USP Class VI Biological Reactivity Test and FDA listed materials per CFR 21

Advanced Features

Specification	Detail
Packaging Economy	Bulk packaging in case quantities: 5 inch - 48 per carton, 10 inch - 24 per carton, 20 inch - 12 per carton, 30 inch - 12 per carton, 40 inch - 9 per carton

Physical Specifications

Specification	Detail
Outside Diameter	MPT: 2.55" (6.48 cm), PRMXT: 2.7" (6.87 cm)
Approximate Surface Area	6.8 square feet per 10" equivalent
Lengths	5 inch (12.7 cm), 10 inch (25.4 cm), 20 inch (50.8 cm), 30 inch (76.2 cm), 40 inch (102 cm)

Product Overview

Utilizing a proprietary PTFE membrane casting method we are able to achieve a pore configuration that optimizes cartridge flow rates with absolute and reliable particle and microorganism retention. This unique combination of features positions them as one of the most reliable and economical PTFE membranes in the market.

These cartridges are manufactured and tested in our 3rd party certified clean room with components that meet USP Class VI Biological Reactivity Test resulting in extremely low extractables. These high purity elements are perfect for biopharmaceutical, microelectronics and high purity chemical applications.

The Pur-MAXX T now offers a Special Pleat option, which provides expected surface area improvements of as much as 25%. This optimized pleat geometry option was developed for the filtration of process fluids that require a high degree of particle retention and/or constant bacterial barrier for effective sterilization.
