MAXX-Trap 6.75 inch OD Housing HSL Polypropylene or Microglass Hybrid Elements
Strainrite continues its tradition of state-of-the-art advanced filtration innovation with the MAXX-Trap, a continuous, high-solids loading (HSL) hybrid, that utilizes long strand small and large diameter fibers to provide a high solids loading, absolute-rated, pleated depth filter.
Technical Specifications
Filtration Performance
| Specification | Detail |
|---|---|
| Micron Rating |
MF - 0.25, 0.5, 1, 2.5, 5, 10, 20, 30, 50 GF - 0.2, 0.5, 1, 3, 5, 10, 15 |
| Maximum Operating Temperature | 180°F (82°C) continuous duty |
| Maximum Differential Pressure | 35 PSID @ 70°F (21°C) |
| Maximum Flow Rates | 20" - 175 GPM | 40" - 350 GPM | 60" - 500 GPM |
| Recommended Change-Out | 25 PSID |
Materials & Compliance
| Specification | Detail |
|---|---|
| Filter Media | Borosilicate microglass, polypropylene microfiber |
| End Caps | Polypropylene |
| Support Material | Polypropylene, polyester |
| Molded Cage | Polypropylene |
| O-Rings | Buna N, fluorocarbon, EPDM, silicone, FEP encapsulated silicone |
| Construction Method | Thermal bond |
Physical Specifications
| Specification | Detail |
|---|---|
| Nominal Top Outside Diameter | 6.75" (17.1 cm) |
| Lengths | 20" (50.8 cm) | 40" (101.6 cm) | P1 - 12" (30.5 cm) | P2 - 26" (66.3 cm) |
Product Overview
This hybrid filter easily works with most standard 6.75" outside diameter housing. The binder-free depth media is excellent for removing gels and offers more than twice the surface area compared with industry standard non-pleated depth filters.
The increased surface area provides higher flow rates at reduced pressure, resulting in increased filter life. Our 100% polypropylene construction provides an excellent range of compatibility for your most demanding applications.
Features & Benefits
High efficiency media provides reliable, consistent and repeatable filtration
99% rated filter media for consistent and repeatable performance
Large diameter pleat configuration for high flow rates
Capable of flow rates up to 500 GPM per filter
Injection molded cage for superior strength and element integrity
Thermally bonded construction
High dirt holding capability due to extensive surface area requiring fewer filter changeouts
Inside-out filter retains all contaminants inside the filter during changeouts
