Trap-Rite
Strainrite continues its tradition of state-of-the-art advanced filtration innovation with the Trap-Rite. A unique polypropylene depth filter, that utilizes long strand small and large diameter fibers to provide a high solids loading, absolute-rated, pleated depth filter. This binder-free depth media is excellent for removing filter aid particles from bright beer. Trap-Rite also offers more than twice the surface area compared with industry standard non-pleated depth filters. The increased surface area provides higher flow rates at reduced pressure, resulting in increased filter life.
Technical Specifications
Filtration Performance
| Specification | Detail |
|---|---|
| Retention Rating | 1, 5, 10 |
| Maximum Differential Pressure | Forward: 75 psid (5.1 bar) @ 75°F (24°C), 40 psid (2.8 bar) @ 180°F (82°C) |
| Maximum Operating Temperature | 180°F (82°C) continuous duty |
Materials & Compliance
| Specification | Detail |
|---|---|
| Filter Media | Polypropylene microfiber composite |
| End Caps | Polypropylene |
| Pleat Support Material | Polypropylene |
| Cage/Core | Polypropylene |
| Seals | Buna N, Fluorocarbon, EPDM, Silicone, FEP Encapsulated Fluorocarbon, FEP Encapsulated Silicone, PTFE Foam, PTFE Hard |
| Construction Method | Thermal bond |
| Toxicity | All components meet all relevant USP XXII Class VI test for biological safety and FDA requirements for contact with food and beverage per 21CFR177.1520 |
Advanced Features
| Specification | Detail |
|---|---|
| Packaging Economy |
Bulk packaging in case quantities to reduce material disposal: 5 inch - 48 per carton | 10 inch - 24 per carton | 20 inch - 12 per carton | 30 inch - 12 per carton | 40 inch - 9 per carton |
Physical Specifications
| Specification | Detail |
|---|---|
| Outside Diameter | 2.55" (6.48 cm) |
| Lengths | 5 inch (12.7 cm), 10 inch (25.4 cm), 20 inch (50.8 cm), 30 inch (76.2 cm), 40 inch (102 cm) |
Product Overview
All polypropylene construction materials are CFR 21 listed for direct food contact, which makes this filter ideal for a broad range of applications.
Features & Benefits
Absolute-rated media provides reliable, consistent and repeatable filtration
Low pressure drops yield higher flow rates and reduced processing time
100% polypropylene, FDA compliant with CFR 21
Removes filter aid particles
Very high contaminant holding capacity
Maximized pleat design for greater surface area, ensuring longer service life, fewer change outs and reduced operating costs
Excellent resistance to typical brewery use chemicals
Thermally bonded construction, eliminating particle bypass
Recommended Vessels
Vessels and housings recommended for use with this product.
Markets & Applications
Brewery Chemicals
Filter Aid Particle Removal
Food & Beverage Applications
