Guard-Rite Microglass over Polyethersulfone Beverage Pre-Final Filtration
Created for beverage pre-final filtration, the Guard-Rite is the pre-final filter, to cost effectively reduce bioburden before final filtration and packaging. With a depth layer and synchronized final filtration layer optimized to extend final filter life with a stainless steel insert for steam or hot water sanitization.
Technical Specifications
Filtration Performance
| Specification | Detail |
|---|---|
| Absolute Rated Retention |
561 = 1µm Microglass over 0.65µm Polyethersulfone 562 = 2µm Microglass over 0.65µm Polyethersulfone 563 = 3µm Microglass over 0.65µm Polyethersulfone 568 = 0.8µm Microglass over 0.65µm Polyethersulfone |
| Maximum Differential Pressure | Forward: 75 psid (5.1 bar) @ 75°F (24°C), 40 psid (2.8 bar) @ 180°F (82°C) |
| Maximum Operating Temperature | 180°F (82°C) continuous duty |
Materials & Compliance
| Specification | Detail |
|---|---|
| Filter Media | Microglass over Polyethersulfone |
| End Caps | Polypropylene |
| Pleat Support Material | Polypropylene Polyester |
| Cage/Core | Polypropylene |
| Seals | Buna N, Fluorocarbon, EPDM, Silicone, FEP Encapsulated Fluorocarbon, FEP Encapsulated Silicone, PTFE Foam, PTFE Hard |
| Construction Method | Thermal bond |
| Toxicity | Cartridge materials meet USP Class VI and CFR 21 for food and beverage contact |
Advanced Features
| Specification | Detail |
|---|---|
| Sterilization | Cartridge can be sterilized via steam or autoclave: 20 times at 275°F (135°C). Cartridge may be sanitized in place with common sanitizing agents; contact factory for chemical compatibility. |
| Packaging Economy | Bulk packaging in case quantities to reduce material disposal: 5 inch - 48 per carton | 10 inch - 24 per carton | 20 inch - 12 per carton | 30 inch - 12 per carton | 40 inch - 9 per carton |
Physical Specifications
| Specification | Detail |
|---|---|
| Outside Diameter | 2.7" (6.87 cm) |
| Approximate Surface Area | 5 square feet per 10" equivalent |
| Lengths | 5 inch (12.7 cm), 10 inch (25.4 cm), 20 inch (50.8 cm), 30 inch (76.2 cm), 40 inch (102 cm) |
Product Overview
Guard-Rite is engineered to provide cost effective removal of particles and reduction of beverage-spoiling micro-organisms. The superior flowing membrane ensures that flavor and color stay in your beverage.
Every Guard-Rite filter comes with a certificate of conformance and is manufactured to meet the highest cleanliness standards.
Features & Benefits
Reliable non fiber releasing media
Synchronized media
Thermally bonded construction
No additives or glue
All materials of construction are FDA compliant with CFR Title 21
Thermally bonded construction without the use of adhesives or binders, resulting in lower extractables
High strength design allowing for extended use and multi-autoclave cycles
Recommended Vessels
Vessels and housings recommended for use with this product.
Markets & Applications
Prefiltration & Clarification for Final Sterilizing Grade Filter Protection
Prefiltration of Beer
Prefiltration of Juice
Prefiltration of Wine
